How do I connect a battery cabinet to an ups?
In systems with more battery cabinets, only the system BMS of battery cabinet 1 (the battery cabinet closest to the UPS) is connected to the UPS. Remove signal cable 0W13441 between the SMPS I/O port and the DRY CONTACT ports on battery cabinet 2 and battery cabinet 3. • SG IO 1: Used for sending signals for minor and major alarms to the UPS.
How is UPS & battery cabinet shipped?
The UPS cabinet is divided into two sections palleted separately for shipping and battery cabinet is shipped separately. The sections are shipped bolted to wooden pallets and protected with outer protective packaging material. The Battery cabinet is shipped bolted to a pallet and covered with outer protective packaging material.
Why is a battery cabinet dangerous?
• The battery cabinet contains an internal energy source. Hazardous voltage can be present even when the UPS system is disconnected from the utility/ mains supply. Before installing or servicing the UPS system, ensure that the units are OFF and that utility/mains and batteries are disconnected.
How do I reinstall a battery cabinet?
Perform the following steps on all battery cabinets in the battery solution. a. Remove the cover in front of the start-up button and push the start-up button. • The PSU2 LED and the POWER LED will turn on. • The ABNORMAL and ALARM LEDs should remain off. b. Reinstall the cover in front of the start-up button.
What clearances are required around a battery cabinet?
The clearances required around the cabinets are to be followed from UPS ("Installation Plan" section) and battery cabinet manuals ("Installation Plan and Unpacking" section) As a result of the connected loads high leakage current is possible. Connection to earth ground is required for safety and proper product operation.
How do you level a battery cabinet?
Lower the levelling feet until they connect with the floor - use a bubble-leveler to ensure that the cabinet is level. 4. Push the second right-most battery cabinet into position, align with the seismic anchoring (if any), and level the battery cabinet as described in step 2 and step 3. 5.
